A2 INSTALLATION MANUAL
8 Ohm Speakers
• Audio Output to Line Inputs 1 & 2
Each Zone’s Speakers Volume Ramps Up & Down Simultaneously
A2
RL
Line Level
Analog Audio
Output
8 Ohm
Speakers
8 Ohm
Speakers
Maximum # of 8 Ohm
speaker pairs without
Volume Controls
4
8 Ohm
Speakers
8 Ohm
Speakers
Figure 2-6: 8 Ohm Speaker Example
