A2 INSTALLATION MANUAL
Appendix A: Specifications
Audio Section
Power Rating - Output Power
60WPC RMS @ 8 Ohms
100WPC RMS @ 4 Ohms
150WPC RMS @ 2 Ohms
Frequency Response
20Hz to 20kHz, -.5dB
Full Power Bandwidth
5Hz to 30kHz
Signal-To-Noise
> 110dB (A-weighted)
Channel Separation
>70dB @1kHz
Total Harmonic Distortion
< .01% @ 1kHz
Intermodulation Distortion
< -90dB
Voltage Gain (AV)
0 - 28, front panel adjustable
Input Impedance
33k Ohms
Connectors
Input/Loop Outputs
Gold RCA Phono
Speaker Outputs
Gold 5 Way Binding Posts
Power
AC Power Requirements
120 VAC, 440 Watts
Current Draw
3.7A @120VAC
Triggers
Remote Trigger Inputs 5 to 24V AC/DC
Remote Trigger Outputs +12 VDC @0.1A
Dimensions/Weight
Dimensions w/ Feet (1U w/o Feet)
17 W x 2 1/4 H x 11 D (in)
432 W x 58 H x 280 D (mm)
Weight
16 lbs/7.2 kg
