A2 INSTALLATION MANUAL
3. Once the unit is securely mounted, install the entire assembly into a standard 19” equipment rack from the front
using four rack screws (not included) as shown in Figure B-3.
19" Equipment Rack
Rack Screws
Figure B-3
