11
Control Panel Menu Structure
Config
Channel Mode
Channel 4 (4ch DMX mode)
Channel 7 (7ch DMX mode)
Channel 8 (8ch DMX mode)
Channel 16 (16ch DMX mode)
Pixel 4 (4ch DMX pixel control)
Pixel 8 (8ch DMX pixel control)
Key Mode
Key Lock
Menu buttons lock after 30sec of
inactivity (push more than once to
temporarily unlock buttons).
Key Unlock
Menu buttons are not locked.
Load Default
Load Default Resets all values to
default
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
Set the Starting DMX Address:
The default mode for the fixture is DMX, so the first menu item that you can edit is the starting DMX ad-
dress.
1. Press the <UP/DOWN> buttons until you reach Address.
2. Push the <ENTER> button.
3. Use the <UP/DOWN> buttons to select a channel from 001-512.
4. Press the <ENTER> button to confirm.
5. Press the <ESC> button to return to the main menu.
Select the DMX Channel Mode:
1. Press the <UP/DOWN> buttons until you reach Config.
2. Push the <ENTER> button.
3. Using the <UP/DOWN> buttons, highlight DMX Mode, then press <ENTER>.
4. Use the <UP/DOWN> buttons to select 1, 3, 4, 7, 8, 16, or 4/8 pixel modes.
5. Press <ENTER>, and then press the <ESC> button until you reach the Address screen.
Master/Slave Mode:
1. Disconnect fixture(s) from any DMX signal source.
2. Set each fixture to matching DMX modes.
3. Connect all fixtures together via DMX. The first fixture in the DMX chain will be the master, followed by
the slave fixtures.
4. Connect DMX controller to the master unit for DMX control.
Load Default Settings:
1. Press the <UP/DOWN> buttons until you reach Load Default.
2. Push the <ENTER> button.
Auto & Standalone Modes:
Allows a single or Master/Slaved units to run factory installed programs at user selectable speeds.
