MAIN MENU OPTIONS / VALUES (Default Settings in BOLD) DESCRIPTION
Personality
Te m p era t u re
C/F
Celsius
Temp C/F
Fahren
Initial Status
PAN =XXX
......
Initial eect position
Select Signal
DMX Only
Select SignalArt-Net
sACN
Ethernet IP XXX. XXX. XXX. XXX Ethernet IP
Ether Mask IP XXX. XXX. XXX. XXX Ether Mask IP
Set Universe 000~32767 Setting Art-Net Universe
Dimmer Mode
Standard
Dimmer Mode
Stage
TV
Architectural
Theatre
Stage2
Delay 0s, 0.1s, 0.2s ... 10s
Refresh
1200, 900-1500,, 2500, 4000, 5000, 6000,
10000, 15000, 20000, 25000(Hz)
Refresh Frequency Rate
Setting
DimmerCurve Linear, Square, Inverse Square, S-Curve DimmerCurve Setting
ResetDef
ON PassCode
Restore factory settings
OFF
Reset
Function
Reset All
Reset Function
Reset Pan&Tilt
Reset Colors
Reset Gobos
ResetZoomModules
Reset Others
Eect Adjust
Test Channel Test function
Manual Control
PAN =XXX
:
Fine adjustment of the lamp
Calibration
Calibrate Password
Pan=XXX
:
Password “050”
Calibrate and adjust the
eects to standard/right
position
User Mode Set User Mode
Standard Mode
Extended Mode
User’s mode to change channel
numbers
Edit Program
Select Program
Auto Pro Part 1 = Program 1 ~ 10 Program 1
Select Programs To Be RunAuto Pro Part 2 = Program 1 ~ 10 Program 1
Auto Pro Part 3 = Program 1 ~ 10 Program 1
Edit Program Prog 1 : Prog 10
ProgTest Testing Program
Step 01 = SCxxx Program In Loop
Step 64 = SCxxx Save and Exit
Edit Scenes
Scene 001 ~ Scene
250
Pan,Tilt,……
– Fade Time –
– Scene Time –
Input By Out
Save and Automatically
Return Manual Scenes Edit
Rec. Controller XX~XX Automatic Scenes Recorder
