S Y S T E M M E N U
FUNCTION - Auto Program
Dene xture mode (Primary or Alone) for running Auto Programs. Select desired internal
programs under “Select Program”, set the number of steps under “Edit program”, and edit
individual scenes under “Edit Scenes”.
PERSONALITY - Status Settings - Address Via DMX
When ON, dene the desired DMX address via an external controller.
NOTE: This process assumes the xture DMX address is set to 001. If xture DMX address is
not at 001, you must adjust the channel numbers accordingly in order for this feature to work.
For example: if your xture address is 010, then Channel 1 becomes Channel 10, Channel 2
becomes Channel 11, and Channel 3 becomes Channel 12.
1. Connect the xture to the external controller and power ON.
2. Set the DMX value of Channel 1 on the controller to (7).
3. Set the DMX value of Channel 2 on the controller to (7) or (8).
When set to (7), the DMX address can be set between (1) and (255).
When set to (8), the DMX address can be set between (256) and (511).
4. Using Channel 3 on the controller set the desired DMX address of the xture.
Example 1:
If the desired DMX address is 57, set Channel 1 to a value of (7), set Channel 2 to a value
of (7), and then set Channel 3 to a value of (57).
Example 2:
If the desired DMX address is 420, set Channel 1 to a value of (7), set Channel 2 to a value
of (8), and then set Channel 3 to a value of (164). (256+164=420)
5. After setting Channel 3 to the desired DMX address value, wait approximately 20 seconds
for the xture to complete the address reset function.
PERSONALITY - Status Settings - Movement Speed
Select Movement Speed (Normal, Slow).
NOTE: For hanging position only use slow speed
PERSONALITY - Service Settings - Password (050)
NOTE: The Service Password MUST be entered in order to access the following menus:
Clear Err. Info .
PERSONALITY - Display Setting - Key Lock
When ON, Control Panel buttons lock automatically after exiting main menu for 15 seconds. To
unlock, keep MODE/ESC button pressed for 3 seconds.
PERSONALITY - Dimmer Curve
Select dimming curve (Linear, Square, InverseSquare, S-Curve).
PERSONALITY - Reset Default (011)
