S Y S T E M M E N U
ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THIS FUNCTION!
NOTE:SAVED WHITE BALANCE IS ERASED AFTER A RESET IS PERFORMED!
This function restores all xture settings to the factory default settings. The password is 011
and must be entered each time a reset is performed.
EFFECT ADJUST - Test Channel
Auto test each individual channel function independently from the DMX control board.
EFFECT ADJUST - Manual Control
Select and manually test and ne adjust each individual channel function Independently from
DMX control board. This function will center PAN and TILT motors and set dimmer to 100%.
PAN and TILT functions will still operate if the xture needs to be positioned to a at clear
surface. With the individual functions, you can focus the light on a at surface (wall) and
perform ne adjustments.
EFFECT ADJUST - Calibration
ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THIS FUNCTION.
This function allows small adjustments to be made to the Pan, Tilt, and Zoom movements to
compensate for ware or in the event a sensor has been knocked slightly out of place. Because
improper use of this function can result in undesired operation this function has been
password protected. The password is 050 and must be entered each time the calibration menu
function is entered. Because calibration is an extremely delicate procedure, instructions on
performing this action are left out of this manual. For a rst-time calibrator, please contact
our customer support team for step-by-step instructions.
EDIT PROGRAM - Rec. Controller
The xture features an integrated DMX-recorder by which you can transmit the programmed
scenes from your DMX-controller to the moving head. Adjust the desired scene numbers via the
encoder (from – to). When you call up the scenes at your controller, they will automatically be
transmitted to the moving head.
