Elation Proteus Lucius - Page 33

3 3
Features subject to change without notice
MODE/CHANNEL
VALUE FUNCTION
HOLD
TIME
DEFAULT SNAP
Standard Extended
14 19
Rotating Gobo2 Index, Rotation
0-127 Gobo indexing
128-189 Clockwise gobo scroll from fast to slow
190-193 No rotation
194-255 Counter-clockwise gobo scroll from slow to fast
15 20
Rotating gobo2 ne indexing:
0-255 Fine indexing
16 21
Fixed gobo
X
0-9 Open
10-19 Gobo 1
20-29 Gobo 2
30-39 Gobo 3
40-49 Gobo 4
50-59 Gobo 5
60-69 Gobo 6
70-77 Gobo 7
78-93 Gobo 1 shake slow to fast
94-109 Gobo 2 shake slow to fast
110-125 Gobo 3 shake slow to fast
126-141 Gobo 4 shake slow to fast
142-157 Gobo 5 shake slow to fast
158-173 Gobo 6 shake slow to fast
174-189 Gobo 7 shake slow to fast
190-221 Clockwise gobo scroll from fast to slow
222-223 No rotation
224-255 Counter-clockwise gobo scroll from slow to fast
22
Fixed gobo indexing Fine:
X
0-255 Fine indexing
17 23
Rotating prism, Prism/Gobo macros:
X
0-63 Open
64-127 4 Facet Prism
128-135 Macro1
136-143 Macro2
144-151 Macro3
152-159 Macro4
160-167 Macro5
168-175 Macro6
176-183 Macro7
184-191 Macro8
192--199 Macro9
200-207 Macro10
208-215 Macro11
216-223 Macro12
224-231 Macro13
232-239 Macro14
240-247 Macro15
248-255 Macro16
