Elation Proteus Lucius - Page 34

3 4
Features subject to change without notice
MODE/CHANNEL
VALUE FUNCTION
HOLD
TIME
DEFAULT SNAP
Standard
Extended
18 24
Rotating 4 prism index, rotating gobo rotation:
0-127 Prism indexing
128-189 Clockwise prism rotation from fast to slow
190-193 No rotation
194-255 Counter-clockwise prism rotation from slow to fast
25
Rotating 4 prism indexing Fine :
0-255 Fine indexing
19 26
Rotating 4 prism linear:
X0-63 Open
64-255 4 Facet Linear Prism
20 27
4 Prism Linear index, rotating gobo rotation:
0-127 Prism indexing
128-189 Clockwise prism rotation from fast to slow
190-193 No rotation
194-255 Counter-clockwise prism rotation from slow to fast
28
4 Prism Linear indexing Fine :
0-255 Fine indexing
21 29
Focus:
127
0-255 Focus edge adjustment
22 30
Focus Fine:
127
0-255 Focus adjustment Fine
23 31
Zoom:
127
0-255 Zoom adjustment from small to big
24 32
Zoom Fine:
127
0-255 Zoom adjustment Fine
33
Auto Focus :
X
0-50 Auto Focus O
51-100 5m
101-150 7.5m
151-200 10m
201-255 15m
34
AutoFocus Fine:
0-255 Continuous adjustment Fine
25 35
Shutter, strobe:
50
0-31 Shutter closed
32-63 No function (shutter open)
64-95 Strobe eect slow to fast
96-127 No function (shutter open)
128-159 Pulse-eect in sequences
160-191 No function (shutter open)
192-223 Random strobe eect slow to fast
224-255 No function (shutter open)
26 36
Dimmer:
0-255 Intensity 0 to 100%
27 37
Dimmer Fine:
0-255 Dimmer ne
