MODE/CHANNEL
VALUE FUNCTION
HOLD
TIME
DEFAULT SNAP
Standard Extended
34 47
Blade 1A
0-255 Open to Close
48
Blade 1A Fine
0-255 Open to Close Fine
35 49
Blade 1B
0-255 Open to Close
50
Blade 1B Fine
0-255 Open to Close Fine
36 51
Blade 2A
0-255 Open to Close
52
Blade 2A Fine
0-255 Open to Close Fine
37 53
Blade 2B
0-255 Open to Close
54
Blade 2B Fine
0-255 Open to Close Fine
38 55
Blade 3A
0-255 Open to Close
56
Blade 3A Fine
0-255 Open to Close Fine
39 57
Blade 3B
0-255 Open to Close
58
Blade 3B Fine
0-255 Open to Close Fine
40 59
Blade 4A
0-255 Open to Close
60
Blade 4A Fine
0-255 Open to Close Fine
41 61
Blade 4B
0-255 Open to Close
62
Blade 4B Fine
0-255 Open to Close Fine
42 63
Framing Rotation:
0-126 Min (-45 degrees)
127-128 Parallel (0 degrees)
129-255 Max (+45 degrees)
64
Framing Rotation Fine:
0-255 Framing Rotation Fine
65
Framing Speed:
0-255 Speed Max -> Min.
