Elation Proteus Lucius - Page 38

3 8
Features subject to change without notice.
MODE/CHANNEL
VALUE FUNCTION
HOLD
TIME
DEFAULT SNAP
Standard Extended
66
Framing Macro:
X
0-7 OFF
8-15 Macro1
16-23 Macro2
24-31 Macro3
32-39 Macro4
40-47 Macro5
48-55 Macro6
56-63 Macro7
64-71 Macro8
72-79 Macro9
80-87 Macro10
88-95 Macro11
96-103 Macro12
104-111 Macro13
112-119 Macro14
120-127 Macro15
128-135 Macro16
136-143 Macro17
144-151 Macro18
152-159 Macro19
160-167 Macro20
168-175 Macro21
176-183 Macro22
184-191 Macro23
192-199 Macro24
200-207 Macro25
208-215 Macro26
216-223 Macro27
224-231 Macro28
232-239 Macro29
240-247 Macro30
248-255 Macro31
67
Pan / Tilt Speed:
X
0-225 Max to min speed
226-235 Blackout by movement
236-245 Blackout by all wheel changing
246-255 No function
43 68
Control:
0
0-19 Color change normal
20-29 Color change to any position
30-39 Color & gobo change to any position
40-44 Low Noise - Mute
45-49 Low Noise - Studio
50-59 Fan Control - Low
60-69 Fan Control - High
70-79 Fan Control - Auto (Default)
80-84 All motor reset
3s
85-87 Pan / Tilt reset
88-90 Color reset
91-93 Gobo reset
94-96 Focus and Zoom reset
97-99 Other motor reset
