36
Elcomed settings – Thread cutter function (chip breaker mode)
Activate thread cutter setting
Activate or deactivate thread cutter function
M
Switch between programs (P 1, 2, 3, 4, 5, 6)
or exit the thread cutter setting
Activating the thread cutter function is only possible with transmission settings WS-75 and WI-75.
When the thread cutter function is activated, the speed in both clockwise and anticlockwise rotations is 20 rpm
and can no longer be changed. When the pedal (grey) on the foot control is pressed, the thread cutter rotates inwards until
the set torque is reached. When the set torque is reached, the device automatically switches to anticlockwise rotation.
Disengaging and then reengaging the pedal will switch the device back to clockwise rotation.
If the thread cutter function is in anticlockwise rotation, the device can also start with the maximum torque.
Thread cutter function
The thread cutter symbol, instead of the clockwise or anticlockwise rotation symbol, appears on the display in the main
menu. The torque and coolant supply volume can be changed in the main menu.
