15 SPARES
The Model CG60/CG60DL gauge is complete with all the items required to get started and take
measurements (transducers must be ordered separately). Over the life of the gauge replacement items may
be required. The following replacement and optional items are available from your local Elcometer NDT
supplier or directly from Elcometer.
Description Sales Part No.
2.25 MHz 1/4” Potted Side Transducer TX2M25CP-2
5 MHz 1/4” Potted Side Transducer TX5M00CP-4
5 MHz 1/4” Potted Side High Damped Transducer TX5M00CP-10
7 MHz 1/4” Potted Side High Damped Transducer TX7M50CP-6
10 MHz 1/4” Potted Side Transducer TX10M0CP-4
Ultrasonic Couplant, 120 ml (4 oz) TC-24034-1
Ultrasonic Couplant, 360 ml (12 oz) TC-24034-2
Ultrasonic Couplant, High Temperature 340°C (650°F), 60 ml (2 oz) TC-24034-4
Ultrasonic Couplant, High Temperature 480°C (896°F), 60 ml (2 oz) TC-24034-5
A wide range of other transducers are available - see “Transducers” on page 38 for further details.
16 TRANSDUCERS
The Model CG60 and Model CG60DL are capable of performing measurements on a wide range of
materials, from various metals to glass and plastics. Different types of material, however, have different
properties. The following paragraphs highlight the important properties of transducers which should be
considered when assessing a particular measurement task.
