9-4
HOW TO USE YOUR MOTORHOME’S EQUIPMENT
FUNCTIONS (continued)
MINIMUM VOLTAGE CONTROL (BATTERY
PROTECTION)
The electronic battery protection device
disconnects the 12V users when leisure
battery reaches 10V and disables: pump,
lights, awning light, stove, 12V sockets,
Omniventfans, motorised bed and TV
antenna. Symbol ref. 15 is the visual alarm
signal.
It is possible to connect all users for one
more minute by pressing the on/off button
(ref. 4 on control panel).
The control panel automatically turns off with
a voltage lower than 9.5V.
Users are automatically reconnected with a
voltage higher than 13.5V.
This device doesn’t control the the 12V users
connected directly to the leisure battery 132.
TANKS
a) Drinking water tank with electronic probe:
visualisation in % (steps of 5%). b) Waste
water tank with screw probe.
DRINKING WATER TANKALARM
Alarm turns on when drinking water level
goes below 15% of the tank capacity and
automatically turns off when level exceeds
25%. Alarm is acoustic (when engine is off),
visual (symbol ref. 13 blinking).
WASTE WATER TANK ALARM
Alarm turns on when the waste water level
exceeds the screw sensor level.
Alarm is shown acoustically (when engine is
off) and visually with the symbol ref. 14
blinking.
DRINKING WATER TANK REFILLING
This function is used during the drinking
water refilling and indicates the water level
during refilling.
To activate this function press the “test tank”
button ref.2 for more than 2 seconds, until the
“water refilling” is displayed on the screen.
The control panel beeps in order to warn that
tank is getting filled: one short beep at 75%,
two short beep at 85% and a long beep at
95%.
To exit this function press buttons ref. 1 or 2.
AWNING LIGHT AUTOMATIC TURN OFF
An electronic device switches off the awning
light when engine is turned on
DIGITAL CLOCK
To set clock see “SETTING”.
ALARM CLOCK
To set and activate/deactivate the alarm clock
see “SETTING”. To reset alarm press any
test button; there is no delayed alarm!
TEMPERATURE
- Both int. and ext. temperatures have a
sensor, which is placed inside or outside of
the vehicle.
- The precision of the temperature value is ±1
°C.
ELECTRONIC BATTERY SEPARATOR
An electronic device controlled by the ignition
switches on the batteries parallel when the
car battery voltage is over 13,5V and
switches off when engine is off or voltage is
lower than 12.2V. This device operates only
if the B2 leisure battery is connected.
This device controls the relays of the users
depending from exit simulating +OUT D+ (3
way function fridge, awning light, antenna
motion, etc.).
