PRODUCT DATA SHEET
SM ALPHA 1-E.3 GB
2.5 Delta 9 R410A B2 DF / ONG3-9 RC R410A B2 ISR
Model Indoor Unit Delta 9 R410A B2 DF ISR
Model Outdoor Unit ONG3-9 RC R410A B2 ISR
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity (4)
Btu/hr 9210 9890
kW 2.70 2.90
Power input (4) kW 0.75 0.83
EER (Cooling) or COP(Heating) (4) W/W 3.60 3.50
Energy effi ciency class(SII) C C
Power supply
V 230
Ph 1
Hz 50
Rated current A 3.4 3.8
Power factor
0.95 0.95
Prated (IDU)
W 30
Prated (IDU+ODU)
W 1050
Starting current A 16.6
Circuit breaker rating A 10
INDOOR
Fan type & quantity Crossfl ow x 1
Fan speeds H/M/L RPM 1320/-/1100
Air fl ow (1) H/M/L m3/hr 450/-/360
External static pressure Min Pa 0
Sound power level (2) H/M/L dB(A) 53/-/49
Sound pressure level(3) H/M/L dB(A) 41/-/35
Moisture removal l/hr 1.02
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 680x250x180
Net Weight kg 6
Package dimensions WxHxD mm 740x310x248
Packaged weight kg 8.5
Units per pallet units 32
Stacking height units 8 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type,model Rotary,Toshiba(GMCC),PA103X1C-4FZDE1
Fan type & quantity Propeller(direct) x 1
Fan speeds H RPM 780
Air fl ow H m3/hr 1800
Sound power level H dB(A) 59
Sound pressure level(3) H dB(A) 49
Dimensions WxHxD mm 795x610x290
Net Weight kg 33
Package dimensions WxHxD mm 970x650x394
Packaged weight kg 35.5
Units per pallet Units 9
Stacking height units 3 levels
Refrigerant type R410A
Refrigerant chargless distance kg(7.5m) 0.95kg
Additional charge 4m≤Length≤10m: +0g; 10m≤Length≤15m: +50g
Connections between
units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 3/8"(9.53)
Max.tubing length m. Max.15
Max.height
difference
m. Max.7
Operation control type Remote control
Heating elements(Option) kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airfl ow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
