PRODUCT DATA SHEET
SM ALPHA 1-E.3 GB
2. PRODUCT DATA SHEET
2.1 Alpha 7 / CON7 (Alpha)
Model Indoor Unit Alpha 7
Model Outdoor Unit CON 7 (Alpha)
Installation Method of Pipe Flared
Characteristics Units Cooling Only Cooling Heating
Capacity
(1)
Btu/hr 7000 7000 7300
kW 2.05 2.05 2.15
Power input
(1)
kW 0.68 0.68 0.63
EER (Cooling) or COP(Heating)
(1)
W/W 3.01 3.01 3.41
Energy effi ciency class B B B
Power supply V/Ph/Hz 230V/Single/50Hz
Rated current A 3.0 3.0 2.8
Starting current A 15
Circuit breaker rating A 10
INDOOR
Fan type & quantity Crossfl ow x 1
Fan speeds H/M/L RPM 1150/950
Air fl ow
(2)
H/M/L m3/hr 390/320
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 50/44
Sound pressure level
(4)
H/M/L dB(A) 37/32
Moisture removal l/hr 0.8
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 680*250*180
Weight kg 7
Package dimensions WxHxD mm 740*250*310
Packaged weight kg 9.5
Units per pallet units 36
Stacking height units 9 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type, model Rotary,TOSHIBA,PA82X1C-4DZDE
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 850
Air fl ow H/L m3/hr 1200
Sound power level H/L dB(A) 61 62
Sound pressure level
(4)
H/L dB(A) 52 53
Dimensions WxHxD mm 610*235*490
Weight kg 27 27.5
Package dimensions WxHxD mm 720*550*360
Packaged weight kg 30/33.5(with kit) 30.5/34(with kit)
Units per pallet Units 12
Stacking height units 4 levels
Refrigerant type R410A
Refrigerant chargless distance Kg/m 0.72kg/7.5m
Additional charge kg 4m≤length≤10m,0.72kg; 10m<length≤15m,0.8kg
Connections between
units
Liquid line In.(mm) Ф 1/4”(6.35)
Suction line In.(mm) Ф 3/8”(9.53)
Max.tubing length m. Max.15
Max.height difference m. Max.7
Operation control type Remote control
Heating elements kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airfl ow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
