Electra Alpha 7 - Delta 7 DF; GCN 7 RC Specifications

2-2
PRODUCT DATA SHEET
SM ALPHA 1-E.3 GB
2.2 Delta 7 R410A А2 DF / GCN 7 RC R410A A2
Model Indoor Unit Delta 7 R410A A2 DF
Model Outdoor Unit GCN 7 RC R410A A2
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity (4)
Btu/hr 7780 7850
kW 2.28 2.30
Power input (4) kW 0.62 0.67
EER (Cooling) or COP(Heating) (4) W/W 3.70 3.45
Energy effi ciency class(SII) A A
Power supply
V 230
Ph 1
Hz 50
Rated current A 2.8 3.0
Power factor
0.95 0.95
Prated (IDU)
W 30
Prated (IDU+ODU)
W 890
Starting current A 15
Circuit breaker rating A 10
INDOOR
Fan type & quantity Crossfl ow x 1
Fan speeds H/M/L RPM 1050/-/900
Air fl ow (1) H/M/L m3/hr 450/-/380
External static pressure Min Pa 0
Sound power level (2) H/M/L dB(A) 50/-/44
Sound pressure level(3) H/M/L dB(A) 37/-/31
Moisture removal l/hr 0.74
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 680x250x180
Net Weight kg 6
Package dimensions WxHxD mm 740x310x248
Packaged weight kg 8.5
Units per pallet units 32
Stacking height units 8 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type,model Rotary,Toshiba(GMCC),PA82X1C-4DZDE
Fan type & quantity Propeller(direct) x 1
Fan speeds H RPM 830
Air fl ow H m3/hr 1450
Sound power level H dB(A) 60
Sound pressure level(3) H dB(A) 50
Dimensions WxHxD mm 830x545x245
Net Weight kg 31.5
Package dimensions WxHxD mm 870x600x320
Packaged weight kg 34
Units per pallet Units 12
Stacking height units 3 levels
Refrigerant type R410A
Refrigerant chargless distance kg(7.5m) 0.8kg
Additional charge 4m≤Length≤10m: +0g; 10mLength≤15m: +50g
Connections between
units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 3/8"(9.53)
Max.tubing length m. Max.15
Max.height
difference
m. Max.7
Operation control type Remote control
Heating elements(Option) kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airfl ow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
