Electra Alpha 7 - Alpha 9; GCN9 Specifications

2-3
PRODUCT DATA SHEET
SM ALPHA 1-E.3 GB
2.3 Alpha 9 / GCN9 (Alpha)
Model Indoor Unit Alpha 9
Model Outdoor Unit GCN 9 (Alpha)
Installation Method of Pipe Flared
Characteristics Units Cooling Only Cooling Heating
Capacity
(1)
Btu/hr
9000 9000 9650
kW
2.64 2.64 2.83
Power input
(1)
kW
0.87 0.87 0.93
EER (Cooling) or COP(Heating)
(1)
W/W
3.03 3.03 3.04
Energy effi ciency class
B
BD
Power supply V/Ph/Hz 230V/Single/50Hz
Rated current A 3.9 3.9 4.1
Starting current A 21.7
Circuit breaker rating A 10
INDOOR
Fan type & quantity Crossfl ow x 1
Fan speeds H/M/L RPM 1310/1100
Air fl ow
(2)
H/M/L m3/hr 450/360
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 53/49
Sound pressure level
(4)
H/M/L dB(A) 41/35
Moisture removal l/hr 1.2
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 680*250*180
Weight kg 7
Package dimensions WxHxD mm 740*250*310
Packaged weight kg 9.5
Units per pallet units 36
Stacking height units 9 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type,model
Rotary,TOSHIBA,PA108X1C-4FZDE
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 750
Air fl ow H/L m3/hr 1370
Sound power level H/L dB(A) 59 61
Sound pressure level
(4)
H/L dB(A) 49 51
Dimensions WxHxD mm
830x245x545
Weight kg 32.5 33.5
Package dimensions WxHxD mm 880x320x610
Packaged weight kg 35/38.5(with kit) 36/39.5(with kit)
Units per pallet Units 9
Stacking height units 3levels
Refrigerant type R410A
Refrigerant chargless distance kg/m 0.85kg/7.5m 0.9kg/7.5m
Additional charge kg
4m≤length≤10m,0.85kg
10m<length≤15m,0.93kg
4m≤length≤10m,0.9kg
10m<length≤15m,0.98kg
Connections between
units
Liquid line In.(mm) Ф 1/4”(6.35)
Suction line In.(mm) Ф 3/8”(9.53)
Max.tubing length m. Max.15
Max.height difference m. Max.7
Operation control type Remote control
Heating elements kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units). and EN 14511
(2) Airfl ow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
