14-5
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.5 Indoor Unit Alpha 7 DF
No. Item Code Item Description Quantity
1 465100013 Grill /Alpha 7,9 F 1
2 453036500 Filter for DELTA 7/9 2
4 465720127 Front Frame Assy./Delta F 9 1
5 4525987 SCREW COVER 3
6 453070700 Evap. System Assy./Alfa7, 1
7 4525982 AIR OUTLET FRAME 1
8 4523693 DRAIN HOSE 1
9 4525991 LOUVER 1
10 4525992 VER. FLAP A 8
10 4525993 VER. FLAP B 2
11 4523526 BERAING ASSY FAN 1
12 466020000 ImpellerFan98*510/ALPHA79 1
13 4526659 REAR PANEL ASSY 1
14 464220008 Mount Bracket./Low Cost ALPHA 9 1
15 4526000 TUBE CLIP 1
16 4523505R Motor 1
17 4525998 MOTEOR COVER 1
18 4523507 Step motor 1
19 455013401R ISR ISRPowerCord/3G/1.0/2100(187) 1
20 4525988 CABLE LOCKER 1
21 453089600R Display assy. for DELTA EHK:936A034-00 1
22 4516263 SENSOR BASE 1
23 467300198R Controller/Delta 7/9/12 S/W:10V14 1
24 438082 Thermistor Indoor 1
25 4519813 Thermistor room 1
26 453027000 Terminal Cover 1
28 4520416 Defrost cable EXPORT UNITS£© 1
29 438600R Remote controller RC3-RC 973-600-00 1
32 465440009 Frame Left Crank 1
32 465440010 Frame Right Crank 1
