14-7
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.7 Indoor Unit Alpha 12 DF
No. Item Code Item Description Quantity
1 465100014 Grill /Alpha 12 F 1
2 453082900 Filter for DELTA 12 2
4 465720128 Front Frame Assy./Delta F 12 1
5 4525987 SCREW COVER 3
6 453058200 Evap. System Assy./Alfa12 1
7 4527506 Air Outlet 1
8 4523693 DRAIN HOSE 1
9 4527509 Horizontal Flap 1
10 4525992 VER. FLAP A 9
10 4527510 Vertical Flap B 3
11 4523526 BERAING ASSY FAN 1
12 4527111 FAN ASSY PLASTIC 1
13 4527186 IOD-12 REAR PANEL ASSY 1
14 464220007 Mount Bracket./Low Cost ALPHA 12 1
15 4526000 TUBE CLIP 1
16 4527112R Motor Compact 12 1
17 4525998 MOTEOR COVER 1
18 4523507 Step motor 1
19 455013400R ISR ISRPowerCord/3G/1.5/2100(187) 1
20 4525988 CABLE LOCKER 1
21 453089600R Display assy. for DELTA EHK:936A034-00 1
22 4516263 SENSOR BASE 1
23 467300198R Controller/Delta 7/9/12 S/W:10V14 1
24 438082 Thermistor Indoor 1
25 4519813 Thermistor room 1
26 453027000 Terminal Cover 1
28 4520416 Defrost cable EXPORT UNITS 1
29 438600R Remote controller RC3-RC 973-600-00 1
32 465440009 Frame Left Crank 1
32 465440010 Frame Right Crank 1
