14-9
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.9 Indoor Unit Alpha 17
NO. Part NO. Name Quantity
1 453080700 Grill A/ALPHA-17 1
2 453080800 Filter 2
3 4518113
Active Carbon Filter (Optional)
2
4 465720011 Front Frame Assy./ALPHA-17
electra for ISREAL 1
465720010 Front Frame Assy./ALPHA-17
electra for EURO. 1
453101700 Front Frame Assy./ALPHA-17 Johnson 1
5 453081000 Screw Cover 3
6 453102200 Evaporator Assy. 1
7 4518662 Bearing assy fan 1
8 453082400 Impeller Fan 1
9 453102000 LED Display assy./ALPHA-17 1
10 453101600 Air Outlet Frame Assy./ALPHA-17 1
11 4518664 Drain hose 1
12 453101400 Unit Housing Assy./ALPHA-17 1
13 453081900 Mount Bracket Assy. 1
14 4526000 TUBE CLIP 1
15 438600 Remote controller RC3-RC 973-600-00 1
16 4523507 Step motor 1
17 452766401 Power Cord European 2m optional 1
452766400 Power Cord Israel 2m optional 1
18 4518651 Cover Side Motor 1
19 453102100 Resin Motor/ 18W/1200rpm 1000rpm 1
20 452918800 Cover/motor 1
21 453101900 Control Box Assy./ALPHA-17 1
457300010 Controller/Alpha 17, With 5 Poles of Terminal 1
457300011 Controller/Alpha 17, With 6 Poles of Terminal 1
22 4525988 CABLE LOCKER 1
23 436525 SUPPLY CORD LATCH WMN 1
24 438082 Thermistor Indoor coil BLACK 1
25 4519813 Thermistor room 1
26 453027000 Terminal Cover 1
