14-11
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.11 Indoor Unit Delta 17
No. Item Code Item Description Quantity
1 465100015 Grill /Alpha 17 F 1
2 453080800 Filter 2
4 465720182 Front Frame Assy./ Electra Delta Fix 14 1
5 453081000 Screw Cover 3
6 453102200 Evaporator Assy. 1
7 453081100 Air Outlet Frame 1
8 4518664 Drain hose 1
9 4527509 Horizontal Flap 1
10 453081400 A Vertical Flap A 11
10 453081500 B Vertical Flap B 1
11 4518662 Bearing assy fan 1
12 453082400 Impeller Fan 1
13 453101400 Unit Housing Assy./ALPHA-17 1
14 453081900 Mount Bracket Assy. 1
15 4526000 TUBE CLIP 1
16 453102100R ResinMotor/18W/1200rpm1000rpm 1
17 452918800 Cover/motor 1
18 4523507 Step motor 1
19 455013400R ISR ISRPowerCord/3G/1.5/2100(187) 1
20 4525988 CABLE LOCKER 1
21 467300007R Display Board Assy./DELTA EHK: 936A035-0 1
22 4516263 SENSOR BASE 1
23 467300199R Controller/Delta 17/22 S/W:10V14 1
24 438082 Thermistor Indoor 1
25 4519813 Thermistor room 1
26 453027000 Terminal Cover 1
28 4520416 Defrost cable EXPORT UNITS 1
29 438600R Remote controller RC3-RC 973-600-00 1
32 465440001 Grill Left Crank 1
32 465440002 Grill Right Crank 1
