14-14
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.14 Outdoor Unit CON 7 RC
No. Part No. Description Qty
1 436358 L.lifter 1
2 4526671 Front Panel 1
3 4526481 CON Outdoor Grille 1
4 4527483 Screw ST4X10-C-H DK>9 1
5 453044400 Partition plate 1
6 4525427 Clip for capacitance 1
7 455000108 Double patch Capacitor for fan motor 2uF 1
8 236179 2 Poles Terminal Block 1
9 453057000 Pedestal/Control 1
10 4514588 5 Poles Terminal Block 1
11 453054500 Clip/cables 1
12 455000502 Compressor Capacitor With Screw 25uF (CBB65) 1
13 453056700 Rubber grommet/base plate 4
14 452964500 Compressor Assy. PA82X1C-4DZDE(R410A GMCC) 1
15 4510677 Nut With Flange M8 -D=24 GB6187-86 3
16 4524278 Wire assy 1
17 4516637 Out sensor Black 1
18 453045400 Base Plate 1
19 453046100 Low Pressure Stop Valve OD9.53 R410A 1
20 453046200 High Pressure Stop Valve OD6.35 R411A 1
21 4520071 4-W Valve coil for R410A 1
22 453044200 4-W Valve Welding assy 1
23 4518951 4-W valve SHF-4H for R410A 1
24 453045600 Capillary assy 1
25 4526669 Side Panel Painting 1
26 4526668 R lifter 1
27 453057500 Condenser Assy 1
28 4526143 Linker of motor support assy 1
29 453045000 Motor Support 1
30 4523609 Motor YDK20-6L 1
31 4523707 AXIAL FAN 1
32 4526675 Top Cover Painting 1
33 453121500 Install Accessory 1
