EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.16 Outdoor Unit CON 7 ST
No. Part No. Description Qty
1 436358 L.lifter 1
2 4526671 Front Panel 1
3 4526481 CON Outdoor Grille 1
4 4527483 Screw ST4X10-C-H DK>9 1
5 453044400 Partition plate 1
6 4525427 Clip for capacitance 1
7 455000108 Double patch Capacitor for fan motor 2uF 1
8 453057000 Pedestal/Control 1
9 4514588 5 Poles Terminal Block 1
10 453054500 Clip/cables 1
11 455000502 Compressor Capacitor With Screw 25uF (CBB65) 1
12 453056700 Rubber grommet/base plate 4
13 452964500 Compressor Assy. P
A
82X1C-4DZDE(R410
A
GMCC) 1
14 4510677 Nut With Flange M8 -D=24 GB6187-86 3
15 4524278 Wire assy 1
16 453183600 Discharge Pipe Assy 1
17 453045400 Base Plate 1
18 453046100 Low Pressure Stop Valve OD9.53 R410
A
1
19 453046200 High Pressure Stop Valve OD6.35 R411
A
1
20 453112700 Connect Pipe 6.35X0.8 1
21 453126300 Capillary 2.6X1.4X1400 1
22 453112600 Suction Pipe 2 1
23 453112400 Suction Pipe 1 1
24 4526669 Side Panel Painting 1
25 4526668 R lifter 1
26 453057500 Condenser Assy 1
27 4526143 Linker of motor support assy 1
28 453045000 Motor Support 1
29 4523609 Motor YD
K
20-6L 1
30 4523707
A
XIAL FAN 1
31 4526675 Top Cover Painting 1
32 453166600 Install Accessory 1
