EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.20 Outdoor Unit CON 7 ST with easy connection kit
No. Part No. Description Qty
1 436358 L.lifter 1
2 4526671 Front Panel 1
3 4526481 CON Outdoor Grille 1
4 4527483 Screw ST4X10-C-H DK>9 1
5 453044400 Partition plate 1
6 4525427 Clip for capacitance 1
7 453054400 Fixing plate/Terminal Plate 1
8 236179 2 Poles Terminal Block 1
9 453057000 Pedestal/Control 1
10 453080600 Terminal Socket/ALPHA Controller 1
11 453054500 Clip/cables 1
12 455000502 Compressor Capacitor With Screw 25uF (CBB65) 1
13 453056700 Rubber grommet/base plate 4
14 452964500 Compressor Assy. P
A
82X1C-4DZDE(R410
A
GMCC) 1
15 4510677 Nut With Flange M8 -D=24 GB6187-86 3
16 453112800 Power Cord/Compressor 1
17 4516637 Out sensor Black 1
18 453045400 Base Plate 1
19 453046100 Low Pressure Stop Valve OD9.53 R410
A
1
20 453046200 High Pressure Stop Valve OD6.35 R411
A
1
21 453118500 4-W Valve coil/ R410
A
1
22 453183700 4-W Valve Welding assy 1
23 4518951 4-W valve SHF-4H for R410
A
1
24 453045600 Capillary assy 1
25 4526669 Side Panel Painting 1
26 4526668 R lifter 1
27 453057500 Condenser Assy 1
28 4526143 Linker of motor support assy 1
29 453045000 Motor Support 1
30 453057200 Motor 1
31 4523707
A
XIAL FAN 1
32 4526675 Top Cover Painting 1
33 453085100 Connect Pipe Ass
y
.
/
1
/
4'+3
/
8'
/
A
lpha7,9,12RC 1
