2-9
PRODUCT DATA SHEET
SM ALPHA 1-E.3 GB
2.9 Delta 17 R410A B1 DF / ONG3-14 RC R410A B1 ISR
Model Indoor Unit DELTA 17 R410A B1 DF ISR
Model Outdoor Unit ONG3-14 RC R410A B1 ISR
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity (4)
Btu/hr 16040 16720
kW 4.70 4.90
Power input (4) kW 1.40 1.40
EER (Cooling) or COP(Heating) (4) W/W 3.38 3.50
Energy effi ciency class(SII) C C
Power supply
V 230
Ph 1
Hz 50
Rated current A 6.4 6.4
Power factor
0.95 0.95
Prated (IDU)
W 42
Prated (IDU+ODU)
W 1830
Starting current A 28.4
Circuit breaker rating A 15
INDOOR
Fan type & quantity Crossfl ow x 1
Fan speeds H/M/L RPM 1200/ - /1000
Air fl ow (1) H/M/L m3/hr 720/ - /590
External static pressure Min Pa 0
Sound power level (2) H/M/L dB(A) 55/-/50
Sound pressure level(3) H/M/L dB(A) 43/ - /37
Moisture removal l/hr 1.75
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 900x295x200
Net Weight kg 11
Package dimensions WxHxD mm 955x360x270
Packaged weight kg 14
Units per pallet units 24
Stacking height units 8 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type,model Rotary,Panasonic,5KS170EAB21
Fan type & quantity Propeller(direct) x 1
Fan speeds H RPM 910
Air fl ow H m3/hr 2160
Sound power level H dB(A) 64
Sound pressure level(3) H dB(A) 53
Dimensions WxHxD mm 795x610x290
Net Weight kg 40.5
Package dimensions WxHxD mm 970x650x394
Packaged weight kg 43
Units per pallet Units 9
Stacking height units 3 levels
Refrigerant type R410A
Refrigerant chargless distance kg(7.5m) 1.27kg
Additional charge 4m≤Length≤10m: +0g; 10m≤Length≤15m: +150g
Connections between units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max.15
Max.height difference m. Max.7
Operation control type Remote control
Heating elements (Option) kW
Others
(1)
Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2)
Airfl ow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1 meter distance from unit.
