14-22
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.22 Outdoor Unit GCN 7 RC R410A A2
No. Item Code Item Description Quantity
1 4522551 Grille A of GCN 1
2 4523441 Front panel A Painting assy 1
3 464600053 Painting Base ASSY. 1
5 455000108 Double patch Capacitor for fan 1
6 464160018 Partition plate/GCZ 9/12 1
8 455000502 Compressor Capacitor 35uF With Screw 1
10 453047000 Low pressure stop valve for R410A 1
11 453046900 High pressure stop valve for R410A 1
12 4519251 Axial Fan OD=400 1
13 4518022 Cap. Clip 1
14 204107 Cable clip Nylon 1
16 4522766R Motor of outdoor (830rpm) 1
17 464860002 Motor Support Assy. 1
18 463600038 CapillaryAssy.2.6*1.4*(10002400)/GCN7RCR 1
19 201019 Nut M8 3
20 391498 Wire assy 1
21 452964500 Compressor Assy. PA82X1C-4DX2 1
22 469100003 Insulation Felt/ Compressor 1
24 4516637 Out sensor Black 1
25 461600049 4-Way Valve Assy./GCN 7RC R410A 1
26 4520071 4-W valve coil for R410A 1
27 4518951 4-W valve SHF-4H for R410A 1
28 4516857 BIG SIDE COVER 1
29 453086200 Side Plate Painting Assy. 1
29 464770007 Rear Plate/Right Painting Assy/GCZ 9/12 1
30 4514588 5 Poles terminal block 1
31 236179 2 Poles terminal block 1
34 464770001 Rear Plate/Left Painting Assy 1
34 464800000 Guard Net/ODU Painting Assy 1
35 462300037 Condenser Assy/GCZ 12 1
36 4516158 Cover panel Painting assy 1
37 436358 L. lifter 1
38 453085800 Connect Plate/Motor Support 1
To Next Page
