14-28
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.28 Outdoor Unit GCN 12 ST
No. Part No. Description Qty
1 4516158 PAINTED COVER PANEL ASSY. 1
2 4522551 Grill A of GCN 1
3 436358 Left Handle 1
4 4523441 Front Panel A Painting Assy. 1
5 4523862 Base Painting Assy. 1
6 453086200 Side Plate Painting Assy. 1
7 4516857 Big Side Cover 1
8 204107 Cable Clip Nylon 1
9 253046 Clip set PVC 1
10 236332 6 Poles Terminal Block 1
11 236179 2 Poles Terminal Block 1
12 4511168 Wire Clip 1
13 4518022 Cap. Clip 1
14 201130 Nut (For Capacitor) 1
15 203008 Washer (For Capacitor) 1
16 455000108 Double patch Capacitor for fan motor 2uF 1
17 455000504 Compressor Capacitor With Screw 35uF (CBB65) 1
18 4526452 Comp.
ssy P
145X2C-4FT 1
19 4510677 Nut With Flange M8 -D=24 GB6187-86 3
20 391498
W
ire ass
1
21 453047000 Gas Valve 1
22 453046900 Liquid Valve 1
23 453087500 Suction tube 1
24 453087600 Discharge 1 1
25 453091000 Muffle 1
26 453092500 Discharge 2 1
27 4516156 Capillary 1
28 4516156 Back Panel 1
29 453092100 Condensor Assy. 1
30 453086000 Patition Plate 1
31 323156 Motor Support 1
32 4522766 Fan Motor 1
33 4519251 Fan 1
34 4519300 Nut M8 (For Fan) 1
35 453166600 Install Accessory 1
To Next Page
