EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.34 Outdoor Unit GCN 12 ST with easy connection kit
No. Part No. Description Qty
1 4516158 PAINTED COVER PANEL ASSY. 1
2 4522551 Grill A of GCN 1
3 436358 Left Handle 1
4 4523441 Front Panel A Painting Assy. 1
5 4523862 Base Painting Assy. 1
6 453086200 Side Plate Painting Assy. 1
7 4516857 Big Side Cover 1
8 204107 Cable Clip Nylon 1
9 253046 Clip set PVC 1
10 170906 Brass Hex Nut GB6170 2
11 170466 Washer star GB862.2 φ4 2
12 170716 Screw M4x12 GB818-76 2
13 236179 2 Poles Terminal Block 1
14 4511168 Wire Clip 1
15 453080600 Terminal Socket/ Alpha Controller 1
16 201130 Nut (For Capacitor) 1
17 203008 Washer (For Capacitor) 1
18 453054400 Fixing plate/Terminal plate 1
19 455001001 Combinated Compressor Capacitor With Screw (35+2)uF (CBB65) 1
20 4526452 Comp.
A
ssy P
A
145X2C-4FT 1
21 4510677 Nut With Flange M8 -D=24 GB6187-86 3
22 391498
W
ire ass
y
1
23 453047000 Gas Valve 1
24 453046900 Liquid Valve 1
25 453182400 4-Way Valve System Ass
y
. 1
26 453121400 4-Way Valve coil 1
27 4518952 4-Way Valve 1
28 453092800 Capillary assy 1
29 4516156 Back Panel 1
30 4516637 Outdoor Unit Sensor 1
31 453092100 Condensor Assy. 1
32 453086000 Patition Plate 1
33 323156 Motor Support 1
34 453114200 Fan Motor 1
35 4519251 Fan 1
36 4519300 Nut M8 (For Fan) 1
37 453085100 Connect Pipe Ass
y
.
/
1
/
4'+3
/
8'
/
A
lpha7,9,12RC 1
