14-38
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.38 Outdoor Unit ONG3-14 RC R410A B1
No. Item Code Item Description Quantity
1 433218 Front Panel A 1
2 433221 Air Inlet Ring-420 1
3 464600001 Base Plate Painting Assy. 1
5 455000108 Double patch Capacitor for fan 1
6 433217 Partition Plate 1
7 4519300 Nut M5 L 1
8 455000505 Compressor Capacitor With Screw 1
9 201019 Nut M8 1
10 4524595 1/2 Gas Valve for ONG R410A 1
11 4526301 High pressure stop valve R410a 1
12 4519251 Axial Fan OD=400 1
14 204107 Cable clip Nylon 1
15 453012700 Electric Panel 1
16 4520171R Fan Motor (910rpm) 1
17 4527203 Motor Support 1
18 463600041 CapillaryAssy.2.6*1.6*(700800)/ONG3-14R4 1
19 4510677 Nut With Flange M8 -D=24 3
20 391498 Wire assy 1
21 460150011R CompressorAssy./5KS170EAA21Panasonic/ONG 1
22 4527058 Comp. Jacket 1
24 4516637 Out sensor Black 1
25 461600053 4-Way Valve Assy/ONG3-14RC R410A. 1
26 4520071 4-W valve coil for R410A 1
27 4518952 4-W valve SHF-7H for R410A 1
28 433229 Valve Cover 1
29 4519606 Right side panel (painting plate) 1
31 236179 2 Poles terminal block 1
33 4514588 5 Poles terminal block 1
34 433228 Back Side Net 1
35 462300003 Condenser Assy. 1
36 4519614 Painting Top Cover 1
37 433225 Handle 1
38 4526298 Bridge 1
40 4519607 Left Side Panel Painting Plate 1
41 464860054 Painting Insulation Plate Assy/ONG 1
70 452813200 coil stopper 1
