PRODUCT DATA SHEET
SM ALPHA 1-E.3 GB
2.13 Delta 24 R410A / OU7-24C R410A
Model Indoor Unit Delta 24
Model Outdoor Unit OU7-24C
Installation method WALL MOUNTED
Characteristics Units Cooling only Cooling Heating
Capacity
(1)
Btu/hr 23100 23100 24150
kW 6.77 6.77 7.08
Power input
(1)
kW 2.24 2.24 2.35
COP
(1)
W/W 3.02 3.02 2.95
Energy effi ciency class B B D
Power supply V/ Ph /Hz 230/50/1
Rated current A 10.5 11.0
Starting current A 63
Circuit breaker rating A 20
INDOOR
Fan type & quantity CROSS FLOW *1
Fan speeds H/ M/ L RPM 1300 1200 1100
Air fl ow
(2)
H/ M/ L m_/hr 910 820 740
External static pressure Min-Max Pa N/A
Sound power level
(3)
H/ M/ L dB(A) 60 57 55
Sound pressure level
(4)
H/ M/ L dB(A) 47 44 42
Moisture removal L/hr 2.3
Condensate drain tube I.D mm 16
Dimensions W/ H / D mm 1060 295 210
Weight kg 15
Package dimensions W/ H / D mm 1125 360 280
Packaged weight kg 18
Units per pallet Units 16
Stacking height Units 8
OUTDOOR
Refrigerant control CAPILLARY TUBE
Compressor type, model ROTARY
Fan type & quantity AXIAL*1
Fan speeds H / L RPM 850 720
Air fl ow H / L m_/hr 3100 2600
Sound power level H / L dB(A) 67 62
Sound pressure level
(4)
H / L dB(A) 58 54
Dimensions W/ H / D mm 900 680 340
Weight kg 64
Package dimensions W/ H / D mm 985 730 406
Packaged weight kg 67
Units per pallet Units 6
Stacking height Units 2
Refrigerant type
R410A
Refrigerant chargless distance kg/m 1.7 / 7.5
Additional charge g/m 7.5m<Add 30g / <15m
Connections
between units
Liquid line In. 3/8
Suction line In. 5/8
Max. tubing length m. 15
Max. height difference m. 7
Operation control type LCD REMOTE CONTROL
Heating elements kW
Others
(1)
Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2)
Airfl ow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1 meter distance from unit.
