5. PERFORMANCE DATA & PRESSURE CURVES
5.1 Alpha7/CON7
5.1.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OD Coil(
o
C)
Data
ENTERING AIR WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC 2.16 2.24 2.29 2.34 2.38
SC 1.49 1.55 1.61 1.65 1.68
PI 0.48 0.48 0.48 0.49 0.49
20
(1)
TC 2.09 2.20 2.27 2.33 2.38
SC 1.46 1.54 1.60 1.65 1.68
PI 0.52 0.53 0.53 0.53 0.53
25
TC 1.98 2.14 2.25 2.31 2.37
SC 1.42 1.51 1.59 1.64 1.67
PI 0.57 0.57 0.57 0.58 0.58
30
TC 1.85 2.01 2.18 2.25 2.32
SC 1.38 1.46 1.56 1.60 1.63
PI 0.61 0.62
0.62
0.63 0.64
35
TC 1.71 1.86
2.05
2.15 2.25
SC 1.31 1.40 1.52 1.56 1.59
PI 0.66 0.67
0.68
0.69 0.69
40
TC 1.56 1.70
1.85
2.02 2.13
SC 1.23 1.33 1.44 1.48 1.51
PI 0.71 0.72 0.73 0.74 0.75
46
TC 1.35 1.48 1.62 1.79 1.93
SC 1.14 1.22 1.31 1.36 1.39
PI 0.78 0.79 0.81 0.82 0.83
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, an A.S.K Kit is required.
