5-22
PERFORMANCE DATA & PRESSURE CURVES
SM ALPHA 1-E.3 GB
5.11.2 Heating
ENTERING AIR DB ID COIL(
O
C)
15 20 25
ENTERING WB
OD COIL(
o
C)
TH Pl TH Pl TH Pl
-10 1.94 0.82 1.87 0.88 1.79 0.92
-7 2.09 0.84 2.02 0.89 1.94 0.94
-2 2.22 0.85 2.15 0.91 2.07 0.96
2 2.70 0.90 2.59 0.95 2.48 1.01
6 3.81 0.96 3.70 1.03 3.57 1.09
10 4.14 1.02 4.03 1.09 3.92 1.16
15 4.48 1.06 4.37 1.14 4.26 1.22
20 4.72 1.09 4.61 1.18 4.48 1.28
LEGEND
TH – Total Heating Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
