5-34
PERFORMANCE DATA & PRESSURE CURVES
SM ALPHA 1-E.3 GB
5.8.2 Heating
ENTERING AIR DB ID COIL(
O
C)
15 20 25
ENTERING WB
OD COIL(
o
C)
TH Pl TH Pl TH Pl
-10 2.89 1.34 2.78 1.42 2.67 1.49
-7 3.11 1.37 3.00 1.44 2.89 1.52
-2 3.30 1.39 3.19 1.47 3.08 1.55
2 4.02 1.45 3.85 1.54 3.69 1.64
6 5.67 1.56 5.50 1.67 5.31 1.77
10 6.16 1.65 6.00 1.76 5.83 1.88
15 6.66 1.72 6.49 1.85 6.33 1.97
20 7.01 1.77 6.85 1.92 6.66 2.07
LEGEND
TH – Total Heating Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
