Electra SMART+ - Installation

5
5.1.
INSTALLATION INSTALARE
Required cable
Cablul necesar
brown / white
brown
blue / white
blue
orange
orange / white
green/ white
green
UTP cat 5e
(AWG24)
2
3
1
4
maro / alb
maro
albastru / alb
albastru
portocaliu
portocaliu / alb
verde/ alb
verde
EN
IT
EN RO
2
2 / 3 x 0,75 mm
2
2 / 3 x 1 mm
2
3 x 0,75 mm
UTP cat 5e (AWG24)
SCU LCK
230 Vac 50HzSCU
SCU Vcam
≤ 50 m
≤ 100 m
≤ 100 m
≤ 100 m
UTP cat 5e (AWG24)
UTP cat 5 (AWG24)
+ 3 x 0.75
UTP cat 5 (AWG24)
+ 3 x 0.75
+ DVA.1PS02
UTP cat 5 (AWG24)
+ 3 x 0.75
DVA.1PS02 + SAC
VPM
APM
VTM(E),
ATM
Audio
Audio + Video 3.5”
Audio + Video 7”
200 m
100 m
50 m
400 m
200 m
120 m
400 m
400 m
300 m
SACDVA
600 m
600 m
500 m
20
