INSTALLATION
Warning：Before using this unit, please keep it upright for at least 3-4 hours.
This unit can easily be moved from one room to another.
While moving the unit please note that it must always be kept upright and then placed
on an even surface.
1. Assemble the fishtail adaptor on to the hose, by extending the end of the hose and
twisting the fishtail into position (At least 3 full rotations)
2. Assemble the Exhaust hose connector on to the other end of the hose, by extending the
opposite end of the hose and twisting the outlet into position (At least 3 full rotations)
3. Attach the exhaust hose connector onto to the exhaust outlet on
the rear of the air conditioner body, by pushing into position.
4.
Make sure the unit is upright and there are no obstructions to
the air inlets and outlet grills. A minimum of 50cm clearance
should be left between the inlet/outlet grills and any
obstruction.
