Page 4 / 12
170018
P 3000 US 120V POWER-AMP
Pos. Nr.
Ref. No.
Best. Nr.
Part No. Bezeichnung Description
R0005 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0006 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0039 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0040 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0041 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0042 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0043 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0044 348632 WI-DR 2X 0.47 OHM 5.00W 5% resistor 2x 0.47 Ohm 5watt
R0070 341713 WI-DR 4.70 OHM 4.00W 5% resistor 4.70 Ohm 4watt
R0071 341713 WI-DR 4.70 OHM 4.00W 5% resistor 4.70 Ohm 4watt
R0072 341713 WI-DR 4.70 OHM 4.00W 5% resistor 4.70 Ohm 4watt
R0074 341713 WI-DR 4.70 OHM 4.00W 5% resistor 4.70 Ohm 4watt
R0075 341713 WI-DR 4.70 OHM 4.00W 5% resistor 4.70 Ohm 4watt
R0119 348490 WI-SO NTC K 164/100K/J safety component NTC
R0120 348490 WI-SO NTC K 164/100K/J safety component NTC
R0163 348593 WI-SO NTC K 164/2.2K safety component NTC
R0164 348593 WI-SO NTC K 164/2.2K safety component NTC
R0166 302032 WI-SCH 470.00 OHM 2.00W 5% resistor 470 Ohm 2watt
R0173 348847 WI-SO PTC C 1011 120 C 5% safety component PTC
R0178 348847 WI-SO PTC C 1011 120 C 5% safety component PTC
R0200 348966 WI-SO NTC B57164-K101-J 52 safety component NTC
R0201 348966 WI-SO NTC B57164-K101-J 52 safety component NTC
VR001 348674 WI-TRI 250.00 OHM LIN pot trim 250 Ohm lin
VR002 348674 WI-TRI 250.00 OHM LIN pot trim 250 Ohm lin
00035 306397 KODIERSTIFT code plug
871288
PCB-B"L1600/2400/P3000/2000
PCB assy 87128 display
CN004 306395 FEDERLEISTE 2,5MM O 7POL connector female 7-pole
CN07X 344975 MESSERLST. 10POL connector male 10-pin
D0019 336399 LED RT 3MM TLUR 4401 LED red 3mm
D0020 336399 LED RT 3MM TLUR 4401 LED red 3mm
D0021 336399 LED RT 3MM TLUR 4401 LED red 3mm
D0022 336398 LED GN 3MM TLHG 4400/01 LED green 3mm
D0023 336399 LED RT 3MM TLUR 4401 LED red 3mm
D0024 336398 LED GN 3MM TLHG 4400/01 LED green 3mm
D0026 336398 LED GN 3MM TLHG 4400/01 LED green 3mm
D0027 336398 LED GN 3MM TLHG 4400/01 LED green 3mm
D0028 336398 LED GN 3MM TLHG 4400/01 LED green 3mm
D0029 336398 LED GN 3MM TLHG 4400/01 LED green 3mm
VR001 348430 P-DREH 10KOHM LIN B potentiometer 10k Ohm lin
VR002 348430 P-DREH 10KOHM LIN B potentiometer 10k Ohm lin
00005 306397 KODIERSTIFT code plug
862118
PCBAR#P3000US
PCB assy 86211
B0001 346791 BUCHSE-FL. XLR 3POL SW socket XLR 3pole
B0002 346792 STECKER-FL. XLR 3POL SW connector XLR 3pin
B0003 346791 BUCHSE-FL. XLR 3POL SW socket XLR 3pole
B0004 346792 STECKER-FL. XLR 3POL SW connector XLR 3pin
CNASE 306446 FEDERLEISTE 2,5MM O 9POL connector female 9-pole
CNBSE 306446 FEDERLEISTE 2,5MM O 9POL connector female 9-pole
