170018
P 3000 US 120V POWER-AMP
Pos. Nr.
Ref. No.
Best. Nr.
Part No. Bezeichnung Description
S0201 327947 SCHALTELEMENT C42315-A1347- switch element on/off
VR101 348486 WI-TRI 47.00 KOHM LIN pot trim 47k Ohm lin
VR102 348675 WI-TRI 2.50 KOHM LIN pot trim 2.5k Ohm lin
VR201 348486 WI-TRI 47.00 KOHM LIN pot trim 47k Ohm lin
VR202 348675 WI-TRI 2.50 KOHM LIN pot trim 2.5k Ohm lin
VR600 348487 WI-TRI 4.70 KOHM LIN pot trim 4.7k Ohm lin
VR601 348487 WI-TRI 4.70 KOHM LIN pot trim 4.7k Ohm lin
VR700 348675 WI-TRI 2.50 KOHM LIN pot trim 2.5k Ohm lin
00015 348855 SICHER-HALTE-FEDER 122090. fuse clip
00025 306397 KODIERSTIFT code plug
00030 332452 KODIERBRÜCKE 330.0101 SW shorting plug
852428
PCB+B"L2400/P3000
PCB assy 85242 supply A
CN001 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN002 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN006 348676 STIFTLEISTE 3POL MLSS connector male 3-pin
CN010 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN011 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN012 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CN013 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CN014 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CN015 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CN016 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CN017 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CN05A 344862 MESSERLST. 8POL connector male 8-pin
C0001 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0002 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0003 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0004 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0005 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0006 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0007 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0008 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0009 348458 KO-EL 2200.000MF 160V 20% cap electrolytic 2200uF/160
C0010 348459 KO-EL 820.000MF 160V 20% cap electrolytic 820uF/160V
C0011 348459 KO-EL 820.000MF 160V 20% cap electrolytic 820uF/160V
C0012 337597 KO-EL 1000.000MF 50V cap electrolytic 1000uF/50V
C0013 337597 KO-EL 1000.000MF 50V cap electrolytic 1000uF/50V
C0014 341714 KO-SO 0.10MF 275V 20% K safety cap 100nF/275V
C0015 341714 KO-SO 0.10MF 275V 20% K safety cap 100nF/275V
D0001 301254 DIODE 1N 4148 AXIAL diode 1N 4148
D0002 301254 DIODE 1N 4148 AXIAL diode 1N 4148
F0001 302579 SICHER T 500 MA 250V fuse 500mA slow blow
F0002 302579 SICHER T 500 MA 250V fuse 500mA slow blow
F0003 302582 SICHER T 1 A 250V fuse 1A slow blow
F0004 302582 SICHER T 1 A 250V fuse 1A slow blow
G0001 348714 GLRI GBPC 3504 W WIRE LEADS rectifier GBPC-W 3504
G0002 343270 GLRI GBPC 3504 rectifier GBPC-P 3504
G0003 333719 GLRI SKB 250 C1000 L5B rectifier B250 C1000
G0004 331965 GLRI B 80 C1500 G rectifier B80 C1500
G02.2 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
