SPECIFICATIONS
R300 Receiver
Receiver Type Synthesized PLL
Frequency Range (RF)
A Band 618 – 634 MHz
B Band 678 – 694 MHz
C Band 516 – 532 MHz
E Band 850 – 865 MHz
Number of Channels 32
Modulation +/- 40 kHz
Diversity Antenna
RF Sensitivity < 1.0 μV for 12 dB SINAD
Image Rejection > 55dB
Squelch Tone Code plus Amplitude
FCC Certification Approved under Part 15
Power Requirements 12 - 16 VDC, 500mA max
Operating Temperature 5º to 45º C (41º to 113º F)
Dimensions
1.72 in H x 7.8 in W x 8.0 in D
(43 mm H x 206 mm W x 210 mm D)
