17
5. Mute Function – press and hold on/off button for 2 seconds until MUTE appears in the LCD
display and sound mutes. Repeat to turn mute off.
2.3 | Bodypack Transmitter
BP-300 CONTROLS, CONNECTORS AND INDICATORS
1. Antenna – Flexible ¼ wave antenna
2. Power On/Off/Mute Button
3. TA4 Microphone Connector
4. On/Mute LED – Green when transmitter is on, Red when muted
5
1
6
1
2
3 4
7
8
9
continued on next page
