ElectroCraft IQ 5000 - IQ-2000 PDM-150 B Mounting

2-12 Installation P/N 0013-1027-005 Rev A
FIGURE 2.8 IQ-2000 PDM-150B Mounting
AIR INTAKE
AIR INTAKE
AIR INTAKE
[349.3]
[360.7]
[7.0]
[31.8] [69.9] [69.9]
[203.2] [225.8]
[31.8] [139.7]
SW1
U10
L1 AUX
L2/N AUX
L1
L2
L3
DC BUS-
DC BUS+
DC BUS
MOTOR
100-240 VAC 50/60 Hz
R
S
T
TB1
TB2
3
1
2
EXTERNAL SHUNT
INTERNAL
HIGH VOLTAGE
MAY EXIST UP TO FIFTEEN MINUTES
AFTER REMOVING POWER.
STATUS
5
10
P1
DIGITAL INPUTS
1
P2
1
10
DIGITAL INPUTS AND OUTPUTS
P3
STATUS/ANALOG I/O
1
5
5
P4
ENCODER 2
AUXILIARY
P5
ENCODER 1
MOTOR
SERIAL 2
COMPUTER
P6
AUXILIARY
SERIAL 1
P7
WARNING:
1. ALLOW 2.00 (50.8mm) CLEARANCE ABOVE & BELOW UNIT FOR AIR FLOW.
2. ALLOW 3.00 (76.5mm) CLEARANCE IN FRONT OF UNIT FOR CABLES.
NOTES:
1.25
2.75 2.75
8.00
0.27
13.75
1.25 5.50
14.20
8.89
AIR EXHAUST
