Step 2
Fully press the clamping levers (A) on the two door hinges.
Step 3 Close the oven door to the first opening position (approximately 70° an‐
gle).
Step 4
Hold the door trim (B) on the top edge of the door at the two sides and
push inwards to release the clip seal.
Step 5 Pull the door trim to the front to remove it.
Step 6
Hold the door glass panels on their top edge one by one and pull them
up out of the guide.
Step 7 Clean the glass panel with water and soap. Dry the glass panel careful‐
ly.
Step 8 When the cleaning is completed, do the above steps in the opposite se‐
quence.
Step 9 Install the smaller panel first, then the larger and the door.
46/64
CARE AND CLEANING
