Q&CI - Technical Support 15 599 83 20-19 Rev. 02
9.2 Display character representation
9.3 List of functions in service mode
Number
Function test UI action to change the
status
Expected behaviour
- First screen - LED lights up to display UI.
- Second screen -
2 Freezer defrost
heater
Press “Ice Cubes”
a. The freezer evaporator defrost sensor
temperature flashes on the display.
b. Watch for temperature increase with the
heater on.
• It may take a maximum of 5 minutes
for the evaporator to heat up.
Maximum 5 minutes “on” or 45°C
Freezer Evap Defrost Sensor
8 Main valve Press “Ice Cubes”.
a. Main valve (faucet) is activated when “on”;
stops when “off”
