Q&CI - Technical Support 16 599 83 20-19 Rev. 02
11 Cube/crush
solenoid
Press “Ice Cubes”.
a. Solenoid is activated when “on”, deactivated
when “off”.
b. Do not leave solenoid activated for more than
1 minute; it turns off automatically after 1
53 Water valve
dispense + main
valve
Press “Ice Cubes”.
b. Be prepared to collect water at dispenser.
c. Water dispenses when “on”; stops when “off”.
56 Ice maker water
valve+ main valve
Press “Ice Cubes”.
a. Remove ice tray to collect water into a
measuring container to measure the water fill.
b. If collecting water into ice tray, first perform
test number 50 to empty ice tray.
c. Water flows in the tray when “on” and stops
71 Refrigerator
defrost heater
Press “Ice Cubes”.
a. Refrigerator Evaporator Defrost Sensor
temperature flashes on the display.
b. Watch for temperature increase with the
heater on.
c. It may take a maximum 5 minutes for the
evaporator to heat up. Maximum 5 minutes
“on” or 45°C Refrigerator Evap Defrost sensor
threshold.
72 Ice maker defrost
heater
Press “Ice Cubes”.
a. Icemaker Evaporator Defrost Sensor
temperature flashes on the display.
b. Watch for temperature increase with the
heater on.
c. It may take a maximum 5 minutes for the
evaporator to heat up. Maximum 5 minutes
“on” or 45°C IM Evap Defrost Sensor
threshold.
74 VCZ balance
heater
Press “Ice Cubes”.
a. Maximum five minutes “on” continuous.
79 Fill tube heater Press “Ice Cubes”.
a. Maximum five minutes “on” continuous.
10 Auger motor Press “Ice Cubes”.
a. Refrigerator door must be closed.
b. Motor running when “on”; motor stopped when
“off”
13 Refrigerator light Press “Ice Cubes”.
a. Refrigerator lights on when “on”, off when “off”
14 VCZ light Press “Ice Cubes”.
a. VCZ light on when “on”, off when “off”
