Q&CI - Technical Support 17 599 83 20-19 Rev. 02
15 Freezer
evaporator fan
Press “Ice Cubes”.
a. The freezer evaporator fan runs at three
speeds:
• “On”: Fan runs at maximum speed
• “Mi”: Medium speed
• “Off”: Stopped
b. “Lc”: Rotor condition locked.
c. “Ns”: PWM signal that provides duty cycle is
absent and the fan is ““off”.
d. “Np”:12V signal or GND signal is absent and
the fan is “On” or “Mi”.
17 VCZ fan Press “Ice Cubes”.
a. The VCZ fan runs at three speeds:
a. “On”: Fan runs at maximum speed
b. “Mi”: Medium speed
c. “Off”: Stopped
18 Condenser fan Press “Ice Cubes”.
a. The condenser fan runs at three speeds:
a. “On”: Fan runs at maximum speed
b. “Mi”: Medium speed
c. “Off”: Stopped
b. “Lc”: Rotor condition locked.
c. “Ns”: PWM signal that provides duty cycle is
absent and the fan is ““off”.
d. “Np”:12V signal or GND signal is absent and
the fan is “On” or “Mi”.
20 Freezer light Press “Ice Cubes”.
a. Freezer light on when status is “on”, and off
when “off”
38 VCC compressor Press “Ice Cubes”.
a. Compressor is running at maximum speed
when “on”, it is stopped at “off”.
47 Ice chute heater Press “Ice Cubes”.
a. Chute heater is activated when “on”,
deactivated when “off”.
62 Icemaker
evaporator fan
Press “Ice Cubes”.
a. Icemaker evaporator fan is activated when
”on”, deactivated at “off”.
63 Flip mullion
heater DC
Press “Ice Cubes”.
a. DC flip mullion heater is activated when “on”,
deactivated at “off”.
66 Dispenser light Press “Ice Cubes”.
a. Dispenser light on when “on”, off when “off”
70 Refrigerator
evaporator fan
Press “Ice Cubes”.
a. The refrigerator evaporator fan runs at three
speeds:
a. “On”: Fan runs at maximum speed
b. “Mi”: Medium speed
c. “Off”: Stopped
b. “Lc”: Rotor condition locked.
c. “Ns”: PWM signal that provides duty cycle is
absent and the fan is ““off”.
d. “Np”:12V signal or GND signal is absent and
the fan is “On” or “Mi”.
76 VCZ damper
heater
Press “Ice Cubes”.
a. VCZ Damper Heater is activated when “on”,
deactivated when “off”.
