Q&CI - Technical Support 19 599 83 20-19 Rev. 02
24 Freezer drawer Open/Close FZ Reed Switch
a. “Op”: Door is open.
b. “Cl”: Door is closed.
25 VCZ drawer Open/Close VCZ Reed
Switch
a. “Op”: Door is open.
b. “Cl”: Door is closed.
28 Dispenser paddle Press the Dispenser Paddle
a. “On”: Paddle is pressed.
b. “Of”: Paddle is released or not pressed.
29 Refrigerator
sensor
Activates automatically
a. Temperature sensed by refrigerator sensor
displayed in °C or °F.
b. “OP” if open-circuit; “SH” if short-circuit.
30 Freezer sensor Activates automatically
a. Temperature sensed by freezer sensor
displayed in °C or °F.
b. “OP” if open-circuit; “SH” if short-circuit.
31 Refrigerator evap
defrost sensor
Activates automatically
a. Temperature sensed by refrigerator
evaporator defrost sensor displayed in °C or
°F.
b. “OP” if open-circuit; “SH” if short-circuit.
32 VCZ sensor Activates automatically
a. Temperature sensed by VCZ sensor displayed
in °C or °F.
b. “OP” if open-circuit; “SH” if short-circuit.
33 Ambient
temperature
sensor
Activates automatically
a. Temperature sensed by H&T sensor regarding
the ambient temperature displayed in °C or °F.
b. “OP” if open-circuit; “SH” if short-circuit.
39 Freezer
evaporator defrost
sensor
Activates automatically
a. Temperature sensed by freezer evaporator
defrost sensor displayed in °C or °F.
b. “OP” if open-circuit; “SH” if short-circuit.
45 Icemaker tray
sensor
Activates automatically
a. Temperature sensed by icemaker tray sensor
displayed in °C or °F.
b. “OP” if open-circuit; “SH” if short-circuit.
68 Icemaker
evaporator defrost
sensor
Activates automatically
a. Temperature sensed by icemaker evaporator
defrost sensor displayed in °C or °F.
b. “OP” if open-circuit; “SH” if short-circuit.
64 Humidity sensor Activates automatically
a. Relative humidity sensed by H&T sensor in %.
b. “OP” if open-circuit; “SH” if short-circuit.
9.4 Software parameters and firmware versions
After the functional tests, it is possible to view the software parameters and firmware versions of the electronic
boards.
Press the + (refrigerator) icon after the functional tests, “--” is display and after this the sequence described below
starts. .
The --” characters are used as a separator.
