Electrolux EWM1100 - Key to Circuit Diagram

2007-10 SOI/DT-mdm FCPD-dp Quality-fz 57/59 599 70 32-47
8.1.1 Key to circuit diagram
Electrical components on appliance Components on main board
1. Analogue pressure switch
2. NTC temperature sensor
3. Solenoid valve for prewash
4. Solenoid valve for wash
5. Thermal cut-out (drain pump)
6. Drain pump
7. Stator (motor)
8. Rotor (motor)
9. Thermal cut-out (motor)
10. Tachometric generator (motor)
11. Interference filter
12. Door lock unit
13. Heating element (with thermal fuses)
14. Motor with half field
15. Motor without half field
16. Circuit board
17. Drum sensor position (DSP)
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
K1 Heating element relay
K2 Motor relay: clockwise rotation
K3 Motor relay: anti-clockwise rotation
K4 Motor relay: half field power supply (some models)
MOTOR_TY Motor Triac
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
