Electrolux EWM1100 - Summary Table of Alarms

2007-10 SOI/DT-mdm FCPD-dp Quality-fz 14/59 599 70 32-47
5.5 SUMMARY TABLE OF ALARMS
Alarm Possible fault Action/machine status
Reset Page
E11
Tap closed or water pressure too low; Drain tube improperly positioned; Water fill
solenoid valve is faulty; Leaks from water circuit on pressure switch; Pressure switch
faulty; Wiring faulty; PCB faulty.
Cycle is paused with door locked.
START/RESET
18
E13
Drain tube improperly positioned; Water pressure too low;
Water fill solenoid valve is faulty; Water circuit on pressure switch is leaking/clogged;
Pressure switch faulty.
Cycle is paused with door locked.
START/RESET
20
E21
Drain tube kinked/clogged/improperly positioned; Drain filter clogged/dirty; Drain
pump faulty; Pressure switch faulty; Wiring faulty; PCB faulty; Electrical current leak
between heating element and ground.
Cycle is paused (after 2 attempts).
START/RESET
22
E23
Drain pump faulty; Wiring faulty; PCB faulty.
Safety drain cycle - Cycle stops with
door unlocked.
RESET
24
E24
PCB faulty.
Safety drain cycle - Cycle stops with
door unlocked.
RESET
25
E31
Pressure switch; Wiring; Main PCB. Cycle stops with door locked.
RESET
25
E32
Drain tube kinked/clogged/improperly positioned; Drain filter clogged/dirty; Drain
pump faulty;
Water circuit on pressure switch; pressure switch;
Wiring; main board.
Cycle is paused.
START/RESET
26
E35
Water fill solenoid valve is faulty; Leaks from water circuit on pressure switch;
Pressure switch faulty; Wiring faulty; PCB faulty.
Cycle stops. Safety drain cycle.
Drain pump continues to operate (5
min. on, then 5 min. off, etc.).
RESET
27
E38
Water circuit on pressure switches; Pressure switches; Motor belt broken. Heating phase is skipped.
RESET
28
E3A
PCB faulty. Cycle stops with door locked.
RESET
29
E41
Door lock unit faulty; Wiring faulty; PCB faulty. Cycle is paused.
START/RESET
30
E42
Door lock unit faulty; Wiring faulty; PCB faulty. Current leakage from heating element
to ground.
Cycle is paused.
START/RESET
32
E43
Door lock unit faulty; Wiring faulty;
PCB faulty.
(Safety drain cycle) Cycle stops.
ON/OFF RESET
33
E44
PCB faulty. (Safety drain cycle) Cycle stops.
ON/OFF RESET
34
E45
PCB faulty. (Safety drain cycle) Cycle stops.
ON/OFF RESET
34
E51
PCB faulty; current leakage from motor or from wiring.
Cycle blocked, door locked (after 5
attempts).
RESET
35
E52
Motor faulty; wiring faulty; PCB faulty.
Cycle blocked, door locked (after 5
attempts).
RESET
36
E53
PCB faulty. Cycle blocked, door locked.
RESET
40
