- 12 -
DGN-TDS-N 11.03 U. H. / A. B. © Electrolux 599 512 232 EN
H
0
3
A
4. Functionality
Typical display of User interface status:
Zone is hot:
Boost is not possible!
Press both buttons to switch
off the zone rear right!
-button for decreasing
cooking level of zone
front left!
+button for increasing
cooking level of zone
front leftt!
Boost function is on!
4.1 Cooking levels
The Type of cooking levels is configured in the EEPROM of the power board and transmitted to the
user interface with the HOB UI Configuration message.
There are versions with/without the intermediate steps and also with/without the keep warm level
“u” for the European version. For “P” see chapter Boost functionality (Automatic heating up /
Ankochstoss)
Power Levels
Display
European
Swiss variant
(Centronica)
0 0
u
1
2 1
2. 2
3
3. 3
4
4. 4
5
5. 5
6 6
6. 7
7 8
8 9
9 H
P P
