- 6 -
DGN-TDS-N 11.03 U. H. / A. B. © Electrolux 599 512 232 EN
2.1.3 Variant 2 - split vertical
17 Sensors
18 round or rectangular LEDs
6 7-segment displays
size: 135mm x 36mm²
